Panda MD2000 - Specifications; Technical Specifications

1
1 Specifications
1-1 Technical specifications
Table 1-1 Technical specifications @25°C
Input voltage
5 VDC ± 0.25 V
Power
150 mW (Standby); 525 mW (Operating); 850 mW (Max.)
Current
30 mA (Standby); 105 mA (Operating); 170 mA (Max.)
Laser
630-650 nm laser diode
Decoding rate
200 times/sec
Scanning angle
±65°, ±70°, ±42° (Skew, Pitch, Roll)
Print contrast
25% minimum reflection difference
Decode capability
UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN, Code
39, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2
of 5 (Discrete 2 of 5), Matrix 2 of 5, Codabar (NW7), Code 128, UCC/EAN 128
(GS1-128), ISBT 128, Code 93, Code 11 (USD-8), MSI/Plessey, UK/Plessey,
China Post, Telepen, GS1 DataBar (formerly RSS) variants
Indicator
Beeper, LED
Interface supported
RS-232, USB Keyboard, USB virtual COM
Operating mode
Hand-held, Auto-detection (Optional accessory)
Dimensions
Height × Width × Depth：76 mm × 66.5 mm × 168 mm
Weight
121 g, without cable
Cable
Straight 2.0 m
Connector type
RJ-45 phone jack connector
Case material
ABS
Exit window material
PC
Temperature
0° to 50°C (32° to 122°F), Operating; -40° to 60°C (-40° to 140°F), Storage
Humidity
5% to 95% (non-condensing)
Programming method
Manual (reading special barcode)
Program upgrade
Online
Decoding depth
& Min. element width
(1 mil = 0.0254 mm)
3 mil: 27 - 65 mm
4 mil: 27 - 60 mm
5 mil: 18 - 132 mm 10
mil: 10 - 320 mm
13 mil: 16 - 380 mm
15 mil: 13 - 500 mm
20 mil: 19 - 620 mm
30 mil: 25 - 770 mm
