Check digit verification: The check digit verification is optional.
Check digit transmission: By setting Enable, check digit will be transmitted.
Max./Min. code length: Each symbol has own max./min. code length. If both setting of max./min. code
length are “00”s, the setting of global max./min. code length is effective. The length is defined as to the
actual barcode data length to be sent. Label with length exceeds these limits will be rejected. Make sure
that the minimum length setting is no greater than the maximum length setting, otherwise all the labels of
the symbol will not be readable. In particular, you can see the same value for both minimum and maximum
reading length to force the fixed length barcode decoded. Refer to 3-5 Scan trigger mode &
some global settings.
Code ID setting of UPC-A. Code ID setting: Refer to
Insert group selection:3-7 UPC-A.
Start/End transmission: The start character and end character of Code 39
are “*”s. You can transmit all data digits including two “*”s.
“*” as data character: By setting Enable, “*” can be recognized as data character.
Convert Code 39 to Code 32: Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry.
Note that Code 39 must be enabled in order for this parameter to function. Format of Code 32
Code 32 Prefix “A” transmission: By setting Enable, the prefix character “A” can be added to all Code 32
barcodes.
Trioptic Code 39 read: Trioptic Code 39 is a variant of Code 39 used in the marking of magnetic tapes
and computer cartridges. Trioptic Code 39 symbols always contain six characters. Format of Trioptic Code
39
Trioptic Code 39 Start/End transmission: The start character and end character of Trioptic Code 39 are
“$”s. You can transmit all data digits including two “$”s.
