OPERATOR MANUAL Page 14 Learning about the Panini Vision X
2.3 Internal Part Description
1. Document Pressure Plate
2. LED Board
3. Feeder Roller
4. Feeder Sensor
5. Rear Separator Roller
6. Front Separator Rooler
7. Pre-Magnetization Heads
8. Pressure Roller
9. MICR reading head
10. Synchronization Sensor
11. Ultrasonic Double Feeding Sensor
12. Transport Roller
13. Ink-Jet Cartridge Cradle
14. Rear Image Camera
15. Front Image Camera
16. Pocket Sensor
17. Transport Belt
18. Interlock Board
19. Feeder Motor
1
2
3
4
5
6
7
10
9
11
12
8
13
14
15
16
17
18
19
