OPERATOR MANUAL Page 40 Specifications
E13B/CMC7/Automatic
New Panini MICR Plus® exclusive technology with OCR assist feature
Superior MICR recognition and management
Next Generation Contact Image Sensor (CIS) technology (front and rear)
Image format: Bitmap in B/W, 256 shades of gray, Color (Fast and True) and drop out mode. TIFF,
JPEG and Group IV compression
Image Quality Assurance sw (IQA) available as sw option
Image resolution: 100, 200 or enhanced 300 dpi
Advanced Dynamic Thresholding
Superior auto calibrated image quality
Dual Image: up to 5 images (3 front + 2 rear) in one document pass
Panini Vision API control running on:
Windows 2000 S.P. 3, XP S.P. 1, Windows Vista, Windows 7 with USB 2.0 or USB 1.1
ICR Vision function for image snippet definition and download
Easy integration of ICR/Barcode/OCR recognition technology.
3 Tracks Magnetic badge reader
IR (infrared) or UV (ultraviolet) front image capture for security applications
HW: External dongle for temporary and device independent upgrades
SW: OCR Recognition: OCR-A, OCR-B recognition engine
SW: Barcode Recognition: Code 39, Interleaved 2/5, EAN8, EAN13, UPCA, UPCE, Code 128
SW: 2D barcode (PDF 417, Datamatrix)
APPLICATION PC
MINIMUM REQUIREMENT
V X 50, V X 75: Intel Pentium IV, 1.2 GHz, 512 Megabytes Ram
V X 100+: Intel Pentium IV, 2 GHz, 512 Megabytes Ram
On board Diagnostics: tests the functionality of the scanner
Power-on Self Testing: Automatic self testing and photocells calibration when powering the unit
Maximum accessibility to every component to minimize MTTR
Total access to scanner and track area
Firmware upgradeable via PC
POWER SUPPLY INPUT VOLATGE
Autosensing from 100 to 240 Vac, 50 to 60 Hz
Temperature: 15 ÷ 35°C
Humidity: 20 ÷ 80% R.H. Non-Condensing
Specifications subject to change without previous notice.
