OPERATOR MANUAL Page 48 Vision X P Addendum
Technical Specifications of the Panini Vision X P
Vision X P Technical Specifications
PERFORMANCE
3 versions (sw upgradable)
VX P 50: Up to 50 DPM
VX P 75: Up to 75 DPM
VX P 100+: >100 DPM
and PC performance USB2.0 interface
ADDITIONAL OPTIONS
HW: 3 Tracks Magnetic badge reader
IR (infrared) or UV (ultraviolet) front image capture for security applications
HW: External dongle for temporary and device independent upgrades
SW: OCR Recognition: OCR-A, OCR-B
SW: Barcode Recognition: Code 39, Interleaved 2/5, EAN8, EAN13, UPCA,
UPCE, Code 128
SW: 2D barcode (PDF 417, Datamatrix)
IMPROVED AUTOMATIC DOCUMENT FEEDER
2 versions (sw upgradable):
Holding up to 50 documents SF version
Holding up to 120 documents with unlimited continuous feeding FF version
Double feed detection ultrasonic technology*.
Auto-tuning separator roller designed to process varied thickness of documents
and to compensate wear
POCKETSTwo exit pockets capable of holding 100 documents each.
Flexible Sorting Options, based on MICR and/or image
Full pocket sensor .
MAINTENANCE
Maximum accessibility to every component to minimize MTTR
Total access to scanner and track area
Firmware upgradeable via PC
MAGNETIC READER
E13B/CMC7/Automatic
New Panini MICR Plus® exclusive technology with OCR assist feature
Superior MICR recognition and management MICR based sorting
DOCUMENTS SPECIFICATIONS
Weight: Min: 60 gr/m2 (16#) Max: 120 gr/m2 (32#)
SOFTWARE TOOLS
Panini Vision API control running on:
Windows 2000 S.P. 3, XP, Windows Vista with USB 2.0 or USB 1.1
ICR Vision function for image snippet definition and download
Easy integration of ICR/Barcode/OCR recognition technology
*In particular environmental circumstances and typically at very high
altitude, a special calibration could be required.
Please contact your provider for further details.
