MACHINE BASICS
14
3. Located in front of the hand wheel on the right side of the
machine there are 3 oiling spots marked in red. Lubricate with a
single drop of oil.
4. Located on the same side as the hand wheel towards the back
of the machine there is an oil spot marked in red. Lubricate with a
single drop of oil.
5. In the front of the machine there are 5 oiling spots marked in red. They are between 2 and 3, 5 and 6, 8 and
9, 11 and 12, and 14 and 15. Lubricate each hole with a single drop of oil.
6. Place the machine in Needle 1 position. To the right of the
Needle Case (Needle Position 1) are 2 openings. Lubricate with a
single drop of oil.
