ParaBody 660 - Seat, Arm, and Support Assemblies

16
STEP 14
• LOOSELY assemble the TOP BOOM (17) to the top of the MIDDLE (8) & FRONT UPRIGHT (25) using four 3/8 X 2-3/4” BOLTS (85)
and four 3/8” LOCK NUTS (92). See FIGURE 14.
FIGURE 14
92
17
92
85 3/8 X 2-3/4”
85 3/8 X 2-3/4”
25
8
0
1
2
345
6
1/2 1/2 1/2 1/2 1/2 1/2
