FIGURE 34
STEP 34
• Assemble two 3/8” HEX NUTS (108), two SWIVEL SNAP (68), and two 3/8” LOCK NUTS (92) to the 3/8” THREADED SHAFT (106)
as shown in FIGURE 34.
BASE
32
109
106
HEX NUT
68
92
• Position two 3/8 X 1/2” SPACERS (109) inside the bracket on the BASE and slide one 3/8” THREADED SHAFT (106) through the
bracket. See FIGURE 34.
92
68
108
HEX NUT
108
0
1
2
345
6
1/2 1/2 1/2 1/2 1/2 1/2
