Page 27
Module Supervision Options
Viewing GSM IP Information with Digiplex EVO
1) To access Master Programming, enter the [MASTER CODE] then press [0].
2) In Master Programming, press [2] to display the PCS200 IP information.
3) The first screen displays the PCS200 IP Address. Press [] to access
the next screen.
4) The second screen displays the PCS200 IP Port. Press [] to access
the third screen.
5) The third screen displays the PCS200 User PC Software Password. If
you press [] again, the Exit Message will be displayed.
Viewing GSM IP Information with MG/SP / E-Series
1) Press the [] key.
2) Enter [
MASTER CODE].
3) To enter SMS Setup, press [
ARM].
4) Using the [] key, scroll up to [9] GSM IP Address and press [
ENTER].
To return to the GSM menu, press [
ENTER].
5) Using the [] key, scroll up to [10] GSM IP Port and press [
ENTER]. To
return to the GSM menu, press [
ENTER].
6) Using the [] key, scroll up to [11] GSM PC Password (Future use). To
return to the GSM menu, press [
ENTER].
7) Using the [] key, scroll up to [12] Site Name. To return to the GSM
menu, press [
ENTER].
8) To exit the GSM menu, press [
CLEAR].
