Paradox Spectra SP4000 Reference & Installation Manual

Magellan / Spectra SP 31
Part 8: Keyswitch Programming
8.1 Keyswitch Numbering
On-board hardwire control panel zones only.
Keyswitch Numbering allows you to assign any hardwired input in the system to any of the 32 keyswitch zones in the control
panel. UL Note: Do not use keyswitches in UL Listed systems.
8.2 Keyswitch Definitions
Keyswitch Definitions determine how a keyswitch is used.
8.2.1 Maintained Keyswitch
On-board hardwire control panel zones only.
To arm a partition using the Maintained Keyswitch, turn the switch from the ON to the OFF position. Disarm it by setting
the key on the ON position.
8.2.2 Momentary Keyswitch
On-board hardwire control panel zones only.
To arm or disarm a partition using the Momentary Keyswitch, turn the keyswitch to the ON position for three seconds,
then turn it to the OFF position.
8.3 Keyswitch Options
Each keyswitch zone can be programmed with one or more options.
8.3.1 Stay/Sleep Disarm Option (Keyswitch)
On-board hardwire control panel zones only: Option 4
When enabled, the keyswitch can only disarm assigned Stay or Sleep armed partitions. When option [4] is disabled,
the keyswitch can disarm partitions armed using any arming method.
8.3.2 Arm Only (Keyswitch)
On-board hardwire control panel zones only: Option 5
When enabled, the keyswitch can only arm assigned partitions. The type of arming is determined by the other
Keyswitch Options selected.
8.3.3 Stay Arming (Keyswitch)
On-board hardwire control panel zones only: Option 6
Activating the keyswitch will Stay Arm the partition.
8.3.4 Sleep Arming (Keyswitch)
On-board hardwire control panel zones only: Option 7
Activating the keyswitch will Sleep Arm the partition.
Only one of the arming options (Stay, Force, Instant and Regular) can be selected.

Paradox Spectra SP4000 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256 events
StayD Mode	Yes
Expandable via Expansion Modules	Yes
Bus	Yes, 4-wire expansion bus
Battery Backup	12V 7Ah
PGM Outputs	2
