0 Reference & Installation Manual
Part 1: Introduction
1.1 Features
• 32 zones (any of which can be wireless or keypad zones).
• 32 users and 32 remote controls (one per user).
• In-field upgrades: Update the panel’s firmware by connecting it to a PC via a 307USB Interface and then using the Winload
software (V2.80 or higher).
• Menu-driven programming for the Installer, Master, and Maintenance codes. This enables you to program the panel through a
simple and easy to use interface, without the use of section numbers.
• Multiple telephone numbers for event reporting: Three for the monitoring station, five for personal dialing and one for pager
reporting. Up to five persons can now be contacted by the panel in case of alarm.
• Calendar with daylight savings time (enable section [730], option [1] and choose section [731] to put in the Country Code):
You can now select 1 out of 18 different country groups each with its own pre-programmed local daylight savings time. You can
also customize the daylight saving time by programming sections [732] and [733].
• New Sleep arming method: Similar to Stay arming, Sleep arming allows users to remain in a protected area, but provides a
higher level of protection. For example, in a two-story house, the perimeter is protected with Stay arming. With Sleep arming,
the perimeter as well as the main floor is protected (motion detectors, etc.), allowing you to roam the second floor and sleeping
quarters.
• Connect up to 15 hardwire keypads on the 4-wire communication bus.
• Push button power reset: Convenient reset button saves time when a momentary powerdown is required as opposed to having
to physically disconnect the control panel’s power cables. Press and hold the RESET switch for five seconds. The STATUS
LED will start flashing. Within 2 seconds of this flashing, press the reset switch again. The panel will reset to default and
restart. Also, you can reset all programmable sections to factory default values in section [950].
• Available in 433MHz or 868MHz.
• Supports Memory Key (PMC-4 and PMC5).
• RF jamming supervision (section [700], option [5]): The control panel will report a trouble if the RF signal is being jammed.
• Supports SIA reporting format to central station.
1.2 System Overview
1.3 Modules Current Consumption List
Module Description Maximum number per system
K32RF 32-Zone Wireless LED Keypad Module 8
K10V/H, K32, K32+,K32LCD,
K32LCD+, K32LX, K35, K636,
TM50
10 and 32-Zone Hardwired LED and LCD Keypad
Module, Touchscreen
15 total including ZX8
ZX8 ZX8SP 8-Zone Expansion Module 3
RPT1 Magellan Wireless Repeater Module 2
VDMP3 Plug-In Voice Dialer 1
IP100 or IP150 IP Internet Module 1
RTX3 Wireless Expansion Module (Spectra SP only) 1
PCS250 or PCS250G GSM/GPRS Communicator Module 1
RX1 Wireless Receiver Module 1
PGM4 4 output Expansion Module 1
HUB2 2-Port HUB and Bus Isolator 1
Module Current Consumption Module Current Consumption
K10V/H Min. = 44mA / Max. = 72mA K32LX 120mA
K32 Min. = 49mA / Max. = 148mA TM50 Standby:100mA / Alarm: 200mA
K32 + Min. = 49mA / Max. = 148mA TM50 Standby:100mA / Alarm: 200mA
K32LCD Min. = 43mA / Max. = 86mA PCS250 Standby:100mA / Alarm: 450mA
K32LCD + Min. = 43mA / Max. = 86mA PCS250 Standby:100mA / Alarm: 450mA
K32RF Min. = 48mA / Max. = 130mA PCS250G Standby:100mA / Alarm: 450mA
K35 Min. = 30mA / Max. = 70mA RX1 25mA
ZX8 Min. = 29mA / Max. = 31mA IP150 100mA
RTX3 Min. = 61mA / Max. = 143mA PGM4 Min. = 13mA / Max. = 150mA
IP100 Min. = 90mA / Max. = 120mA HUB2 Min. = 24mA / Max. = 50mA
VDMP3 Min. = 28mA / Max. = 28mA K636 Min. = 15mA / Max. = 30mA
