5.3.6. P02 - Error Log Menu
Contains the last 15 fault states in chronological order. The most recent fault (alarm, start inhibit or shutdown) is
stored as item 1. Each item consists of two values: the fault code number and the running hours when the fault
occurred. The display will automatically alternate between these two values. All items are view only.
item
description
units
step
min
max
display*
1
Logged error #1
---
no_edit
---
---
01 . . . Er: 0010 E <> 12345 *
2 to
15
logged error #2
to error #15
---
no_edit
---
---
02
to 15
* All values shown in display column are ONLY examples.
Example: last detected error = Emergency Stop shutdown (fault code 0010E) at 12345 running hrs
5.3.7. P03 - Shutdown Menu
Settings that determine the level or condition at which a shutdown fault is generated.
item
description
units
step
min
max
display*
1
Oil service error
hours
1
-999
1000
H2 10
2
BA filter service error
hours
1
-999
1000
H3 2
3
Cabinet temperature high level
°C/°F
1
41
250
T2 100°C
4
3
rd
stage pressure high level
bar/psi
1
8
Sens.
Range -
5bar
P2 45 bar
5
Delivery pressure high level
bar/psi
1
0.1
65.0
6.5
400.0
60.0
Pd 350 bar
* All values shown in display column are ONLY examples.
5.3.8. P04 - Alarm Menu
Settings that determine the level or condition at which an alarm fault is generated. With yellow mark are the
service / maintenance hours.
item
description
units
step
min
max
display*
1
Oil service alarm
hours
1
-1000
999
H2 190
2
BA filter service alarm
hours
1
-1000
999
H3 18
3
Cabinet temperature high level
°C/°F
1
40
249
T2 90
0
C
4
3
rd
stage pressure high level
bar/psi
1
3
Shtdwn
max -5
P2 40 bar
5
Delivery pressure high level
bar/psi
1
0.1
60.0
6.0
395.0
59.5
Pd 330 bar
* All values shown in display column are ONLY examples.
