Paramina CYCLONE SILENT 30E - Technical Data

User Manual - Cyclone Silent - 1-2018 edition
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860-1
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 5
2. Technical Data
High pressure breathing air compressor, 4 cylinders, 4 stages, air-cooled.
Model:
Cyclone Silent
24E
Cyclone Silent
30E
Cyclone Silent 36E
Cyclone Silent
24E - 420b
Cyclone Silent
30E - 420b
Maximum pressure:
350 bar (5075 psi)
420 bar (6090
psi)
420 bar (6090
psi)
Minimum pressure:
40 bar (580 psi)
40 bar (580 psi)
40 bar (580 psi)
Capacity:
24,0 m3/h –
400 lit/min
30,0 m3/h –
500 lit/min
36,0 m3/h –
600 lit/min
24,0 m3/h –
400 lit/min
30,0 m3/h –
500 lit/min
Ambient temperature:
+5ºC to +45ºC
+5ºC to +45ºC
+5ºC to +45ºC
Oil capacity:
3,0 lit
3,0 lit
3,0 lit
Speed Rotation:
800 rpm
1000 rpm
1200rpm
800 rpm
1000 rpm
Piston stroke:
90 mm
90 mm
90 mm
Cylinder bore:
1
st
stage 105 mm
1
st
stage 105 mm
1
st
stage 105
mm
2
nd
stage 55 mm
2
nd
stage 55 mm
2
nd
stage 55
mm
3
rd
stage 36 mm
3
rd
stage 36 mm
3
rd
stage 36
mm
4
th
stage 14 mm
4
th
stage 14 mm
4
th
stage 14
mm
Working Pressure:
1
st
stage 2,2 bar 2,2 bar
2
nd
stage 10,4 bar 10,5 bar
3
rd
stage 52 bar 54 bar
4
th
stage 225 bar 350 bar
3,6 bar
11 bar
55 bar
410 bar
3,6 bar
11 bar
55 bar
410 bar
Electric Motor:
7,5 kW /10 Hp –
400-440V/50-60
Hz
11 kW / 15 Hp -
400-440V/50-60
Hz
15 kW / 20 Hp -
400-440V/50-60
Hz
7,5 kW / 10 Hp -
400-440V/50-60
Hz
11 kW/15 Hp -
400-440V/50-
60 Hz
Control Voltage:
24 V, 50Hz
24 V, 50Hz
24 V, 50Hz
Dimensions LxDxH:
81x124x178 cm
81x124x178 cm
81x124x178 cm
Weight:
498 - 510 Kg
546 -
560 Kg
551 – 585 Kg
498 - 520 Kg
546 - 570 Kg
