Paramina MISTRAL M6-EM User Manual

User Manual - Mistral M6&M8 - 04-2018 from s.n.1882761 edition
.
PARAMINA SA – Byway Evaggelistrias str. 19300 Aspropirgos, Greece, Tel: 0030 210 5575860
Fax: 0030 210 5575868, email: service@paramina.gr - website: www.paramina-compressors.com 66
ITEM
QTY
PART NR.
DESCRIPTION
1
3
128503502
Anti-vibration pad
2
1
100006001
Compressor Block M6*****
100006000
Compressor Block M8*****
3
1
190500600
Safety valve 1
st
stage (5bar)
4
1
109000000
Intake air filter housing
1
109460302
Intake air filter cartridge
5
1
219000022
Safety valve 2nd - 100bar series @40bar
6
1
154122351
Automatic drain 2
nd
stage (80bar 230VAC N.O.)
7a
1
190000000
Manual drain valve c/w seat & connector 2nd stage w.s.
7b
1
2
190000080
Manual drain valve complete with seat
190008112
Manual drain valve’s seat
8
1
208501610
Condensate separator 2
nd
stage (see drawing at page 48)
9
1
190000890
Intercooler 1
st
stage horizontal
10
1
190000850
Intercooler 2
nd
stage
11
1
190000230
After cooler 3
rd
stage (M6 series)
190000232
After cooler 3
rd
stage (M8 series)
12
1
219004522
Safety valve 3
rd
stage (300 bar) ***
1
219004552
Safety valve 3
rd
stage (200 bar) ***
219004520
Service Kit for safety valves p.n. 219004522 & 219004552 ***
13
1
219004572
Pressure maintaining valve ****
14
1
154122200
Automatic drain 3
rd
stage (250bar 230VAC N.C.)
154122271
Automatic drain 3
rd
stage (350bar 230VAC N.C.)
15
1
208903700
BA Filter Ø80x345 complete
208903710
BA Filter Ø78x375 complete w/ο bleed valve
208905720
BA Filter Ø78x375 complete c/w bleed valve
16
1
103030010
Electric motor 2,2 kW/400V/50-60Hz
103030042
Electric motor 3 kW/400V/50-60Hz
17
1
177742242
Start / Stop Button
18
1
163000102
Electric Hourmeter
19
1
164305121
Pressure switch 40-400 bar
164305012
Pressure switch 30-500b dual for Auto Start / Stop
20
1
122063422
Final stage manometer
21
1
**
Taper bush
1
**
Pulley motor
1
135161242
Taper bush com. block (M8 series only)
1
190001240
Washer flywheel/crankshaft M8
1
136017012
Pulley com. Block (M8 series only)
1
105000982
Inside guard
1
**
V-Belt
1
136401002
Flywheel for Μ6 series compressor
136401000
Flywheel for Μ8 series compressor
2
192200822
Flywheel washer Ø8
1
198000802
Flywheel lock screw Ø8
1
193108302
Flywheel screw M8x30
22
1
401001082
Condensate collecting tank 6ltr
