ITEM
QTY
PART NR.
DESCRIPTION
1
1
128503502
Anti-vibration pads for M6 series compressor
3
Anti-vibration pads for M8 series compressor
2
2
150080252
Wheel
3
1
100006001
Compressor Block M6
100006000
Compressor Block M8
4
1
190500600
Safety valve 1
st
stage (5bar)
5
1
109000000
Intake air filter housing
1
109460302
Intake air filter cartridge
6
1
219000022
Safety valve 2nd - 100bar series @34bar
7
1
154122351
Automatic drain 2
nd
stage (80bar 230VAC N.O.)
8a
1
190000000
Manual drain valve c/w seat & connector 2nd stage w.s.
8b
1
2
190000080
Manual drain valve complete with seat
190008112
Manual drain valve’s seat
9
1
208501610
Condensate separator 2
nd
stage
10
1
190000890
Intercooler 1
st
stage horizontal
11
1
190000850
Intercooler 2
nd
stage
12
1
190000230
After cooler 3
rd
stage (M6 series)
190000232
After cooler 3
rd
stage (M8 series)
13
1
219004522
Safety valve 3
rd
stage (300 bar)
1
219004552
Safety valve 3
rd
stage (200 bar)
219004520
Service Kit for safety valves p.n. 219004522 & 219004552
14
1
219004572
Pressure maintaining valve
15
1
154122200
Automatic drain 3
rd
stage (250bar 230VAC N.C.)
154122271
Automatic drain 3
rd
stage (350bar 230VAC N.C.)
16*
1
208903700
BA Filter Ø80x345 complete
208905700
BA Filter Ø80x535 complete (with two cartridges as an option)
17
3
128502312
Anti-vibration pads motor/engine
18
1
103030030
Electric motor 2,2 kW/220V/50-60Hz
103030010
Electric motor 2,2 kW/400V/50-60Hz
103030044
Electric motor 3 kW/220V/50-60Hz
103030042
Electric motor 3 kW/400V/50-60Hz
104160552
Petrol Engine 5,5 Hp (Honda) (M6-BZ series)
104202052
Petrol Engine 6,5 Hp (Honda) (M8-BZ series)
104001702
Petrol Engine 5,7 Hp (Subaru) (M6-BZS series)
19
1
181021052
Thermal switch for M6-EM simple
181800822
Thermal switch for M6-EM with automatic drains
181800822
Thermal switch for M8-EM simple
181800832
Thermal switch for M8-EM with automatic drains
157000022
Thermal switch for M6-ET
157000042
Thermal switch for M8-ET
20
1
177742242
Start / Stop Button
21
1
163000102
Electric Hourmeter for electric models
163000702
Vibration Hourmeter for Petrol models
22
1
164305121
Pressure switch 40-400 bar
164305012
Pressure switch 30-500b dual for Auto Start / Stop
23
1
190017412
DIN connector base
