11. Restraint belt mounting holes
When using restraint belt, attach the restraint belt to the mounting holes below;
Do not perform the bed operation such as raising the back or knee section base with a restraint belt
attached to the main frame. The patient’s body may be squeezed resulting in injury or the bed may
get damaged or deformed.
●When bedmaking or getting into/out the bed, be careful not to insert fingers or any body parts in the
mounting brackets. It may result in injuly.
There are angle indicators for checking back raise angle at the head side of side-rails, and
for the checking tilt angle at the foot side of side-rails (4 motors type only). Please use only
as a guide.
Angle indicator for Back rise
Angle indicator for Trendelenburg
and Reverse Trendelenburg
Restraint belt mounting holes
Restraint belt mounting hole
Hip section base
