PARAMOUNT BED CA-53380 - Technical Specifications

*Subject to normal manufacturing tolerances
Family Name
A5 Series
Product Name
Electrical Hospital Bed
Model No. (*1)
CA-53380 / IA-53380
CA-54380 / IA-54380 / MA-54380V
860mm
Power cable length
Effective length: 2,500mm
Quantity of motors
3 Motors
4 Motors
Operation
Procedure
Auto contour
Motorized
Back raise
Motorized
Knee raise
Motorized
Hi-lo adjustment
Motorized
Side rail
PE resin mold items
Headboard / Footboard
PE resin mold items
Power supply voltage ／ frequency
100-240VAC ／ 50 / 60Hz
Dimensions
Total length
2,200mm (When the extension frame is retracted)
2,300mm (When the extension frame is used)
Total width
990mm
Total height
755[+20, -10] to 1,105[+20, -10]mm (125mm dia. Casters)
775[+20, -10] to 1,125[+20, -10]mm (150mm dia. Casters)
Mattress base length
2,000mm
Mattress base width
Product weight
115kg
Mattress base height
350[+20, -10] to 700[+20, -10]mm (125mm dia. Casters)
370[+20, -10] to 720[+20, -10]mm (150mm dia. Casters)
Back
raise
Inclination angle
0°to 70°[+3, -7]°
Time required
23sec. (*3)
230kgf (2,250N)
Safe working load (*2)
Material
Mattress base
Made of steel, powder coating (part is resin mold item)
Main frame
Made of steel, powder coating (part is resin mold item)
Knee
raise
Inclination angle
0°to 25°[±4]°
Time required
7sec. (*3)
Hi-lo
adjustment
Height range
350mm
Time required
31sec. (*3)
22sec. (*3)
TR
inclination
Time required
-
22sec. (*3)
-
Inclination angle
0° to 12°[+3, -0]°
1.3 Ah 24V
Battery rated capacity
Actuator Type
Linear actuator (DC motor)
Power consumption
500VA or less
Maximum continuous
operation time
2 min. (stop time: 18min. (*4))
13 years and older
Supported age range
Intended users
Medical professionals (Doctors, nurses, etc.), patients,
close relatives of patients, and maintenance staff
Patient target
group
Minimum user body
mass index (BMI)
17
User weight (min. - max.)
Minimum user height
40 to 195 kg
146 cm
54
*1) CA model, IA model and MA model differ in label description, etc. For more information
about specification, please feel free to contact Paramount Bed or your distributor.
*2) Safe working load: Maximum load with which the bed can be operated. (The total load of user's weight
and incidental items including accessories.)
*3) With no loads.
*4) Time to protect electrical parts from overheating when the bed is used continuously for maximum
continuous operation time (2min).
