25
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Service Manual/Spare Parts
Series F11
Bulletin MSG30-5511-M1/UK
3
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Hydraulic motor/pump
Series F10
Catalogue MSG30-xxxx/UK
Content
Contamination / High speed / Oil temperature
Severe damage in cylinder bore at
the pistons turning point.
Reason is to high speed, the piston
is thrown out in the pherferie and
breaks through the protecting oil
film.
High speed wear at the outher
pherferie on the cylinder barrel. The
protecting oil film can't withstand the
high speed.
There are also cavitation marks on
the cylinder barrel.
From the same cylinder barrel there
are severe cavitation marks in the
cylinder bores due to high speed.
Cavitation
High speed wear
Cavitation
Severe damage in cylinder bore at the
pistons turning point.
Reason is to high speed, the piston is
thrown out in the pherferie and breaks
through the protecting oil film.
High speed wear at the outher pherferie
on the cylinder barrel. The protecting oil
film can’t withstand the high speed.
There are also cavitation marks on the
cylinder barrel.
From the same cylinder barrel there are
severe cavitation marks in the cylinder
bores due to high speed.
Cavitation
High speed wear
Cavitation
