7
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Service Manual/Spare Parts
Series F11
Bulletin MSG30-5511-M1/UK
Disassemble F11
1. Remove the key with a plier. 2. Untighten the screws.
3. Disassemble the retaining ring. 4. Remove the back up ring.
Disassembling
