Parker F11 series - Page 8

Bulletin MSG30-5511-M1/UK
8
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Service Manual/Spare Parts
Series F11
Disassemble F11
5. Remove the shaft seal carefully with
screw driver and hammer.
6. Remove the bearing housing by tapping
carefully underneath with hammer.
7. Carefully remove the shaft package
from housing.
8. Remove all pistons.
Disassembling
