9
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Service Manual/Spare Parts
Series F11
Bulletin MSG30-5511-M1/UK
Disassemble F11
9. Remove shims and guide spacer. Screw
driver can be used carefully.
10. Remove the O-rings from the guide
spacer.
11. Remove the cylinder barrel by holding
the housing as shown on picture and
gently tap to work bench.
12. Remove the valve plate with a hook
tool or retaining ring tool carefully.
Disassembling
