Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
6
For inventory, lead times, and kit
lookup, visit www.pdnplu.com
Tie Rod and Prole Pneumatic Cylinders
P1F Series
Catalog 0980
Technical Data
+ = outward stroke
- = return stroke
Cylinder forces
Bore/piston
rod [mm]
Stroke
Surface
area [cm²]
Max theoretical force in N in relation to applied pressure in bar
1 2 3 4 5 6 7 8 9 10
32/12
+
8.0
80 161 241 322 402 483 563 643 724 804
-
6.9
69 138 207 276 346 415 484 553 622 691
40/16
+
12.6
126 251 377 503 628 754 880 1005 1131 1257
-
10.6
106 211 317 422 528 633 739 844 950 1056
50/20
+
19.6
196 393 589 785 982 1178 1374 1571 1767 1964
-
16.5
165 330 495 660 825 990 1155 1319 1484 1649
63/20
+
31.2
312 623 935 1247 1559 1870 2182 2494 2806 3117
-
28.0
280 561 841 1121 1402 1682 1962 2242 2523 2803
80/25
+
50.3
503 1005 1508 2011 2513 3016 3519 4021 4524 5027
-
45.4
454 907 1361 1814 2268 2721 3175 3629 4082 4536
100/25
+
78.5
785 1571 2356 3142 3927 4712 5498 6283 7069 7854
-
73.6
736 1473 2209 2945 3682 4418 5154 5891 6627 7363
125/32
+
122.7
1227 2454 3682 4909 6136 7363 8590 9818 11045 12272
- 114.7 1147 2294 3440 4587 5734 6881 8027 9174 10321 11468
Cylinder air consumption
Bore/piston
rod [mm]
Stroke
Surface
area [cm²]
Air consumption in l/mm in relation to applied pressure in bar
1 2 3 4 5 6 7 8 9 10
32/12
(G1/8)
+ 8.0
0.016 0.024 0.032 0.040 0.048 0.056 0.064 0.072 0.079 0.087
- 6.9
0.014 0.021 0.027 0.034 0.041 0.048 0.055 0.061 0.068 0.075
40/16
(G1/4)
+ 12.6
0.025 0.037 0.050 0.062 0.075 0.087 0.099 0.112 0.124 0.137
- 10.6
0.021 0.031 0.042 0.052 0.063 0.073 0.083 0.094 0.104 0.115
50/20
(G1/4)
+ 19.6
0.039 0.058 0.078 0.097 0.117 0.136 0.155 0.175 0.194 0.213
- 16.5
0.033 0.049 0.065 0.082 0.098 0.114 0.130 0.147 0.163 0.179
63/20
(G3/8)
+ 31.2
0.062 0.093 0.123 0.154 0.185 0.216 0.247 0.277 0.308 0.339
- 28.0
0.056 0.083 0.111 0.139 0.166 0.194 0.222 0.249 0.277 0.305
80/25
(G3/8)
+ 50.3
0.100 0.150 0.199 0.249 0.298 0.348 0.398 0.447 0.497 0.546
- 45.4
0.090 0.135 0.180 0.224 0.269 0.314 0.359 0.404 0.448 0.493
100/25
(G1/2)
+ 78.5
0.156 0.234 0.311 0.389 0.466 0.544 0.621 0.699 0.776 0.854
- 73.6
0.146 0.219 0.292 0.364 0.437 0.510 0.582 0.655 0.728 0.800
125/32
(G1/2)
+ 122.7
0.244 0.365 0.486 0.607 0.728 0.850 0.971 1.092 1.213 1.334
- 114.7
0.228 0.341 0.454 0.567 0.681 0.794 0.907 1.020 1.134 1.247
+ extending, - retracting free air consumption for 1 cycle, 10 mm inward and 10 mm outward
Weight
Bore
size
mm
P1F-S/A/L/H P1F-T Moving parts Adder for rod lock
Base 0 mm
kg
per 100 mm
kg
Base 0 mm
kg
per 100 mm
kg
Base 0 mm
kg
per 100 mm
kg
P1F-H
kg
P1F-L
kg
32 0.54 0.23 0.49 0.27 0.10 0.09 0.6 0.41
40 0.74 0.32 0.73 0.31 0.19 0.16 0.8 0.44
50 1.22 0.47 1.19 0.52 0.34 0.25 1.0 0.61
63 1.69 0.49 1.68 0.54 0.40 0.24 1.2 1.25
80 2.50 0.73 2.48 0.84 0.73 0.39 1.4 2.45
100 3.65 0.80 3.66 0.88 1.02 0.38 1.6 3.72
125 6.41 1.37 6.30 1.32 2.01 0.63 1.8 6.07
