Parker P1F - Ordering Information; Product Series and Design Options

Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/pneumatics
5
For inventory, lead times, and kit
lookup, visit www.pdnplu.com
Tie Rod and Prole Pneumatic Cylinders
P1F Series
Catalog 0980
Ordering Information
Standard strokes for all P1F cylinders compliant to ISO 4393
(with the exception of stroke 40 mm)
Non standard strokes up to 2000 mm.
Ordering Information
Profile/cylinder design
S Smooth
K Smooth with through rod
L Smooth with dynamic rod lock
1, 3
T Tie-Rods
N Tie-Rods with through rod
P Air reservoir
1
Temperature range
M Polyurethane (PUR) -20°C to +80°C std temp
F Fluoro elastomere (FKM) -10°C to +150°C high temp
2
L Ultrathan polyurethane (TPU-PUR) -40°C to +80°C low temp
2
Q (TPU-PUR) with metallic scraper -30°C to +80°C low temp
3
P1F S- - -032
Cylinder bore size
032 32mm
040 40mm
050 50mm
063 63mm
080 80mm
100 100mm
125 125mm
Piston style
- Standard with magnet
4
F Standard w/o magnet
X Aluminium with magnet
A Aluminium w/o magnet
Cylinder stroke
….
Stroke length in
mm (max. 2000)
Rod extension or trunnion
mounting
0000 Without
P . . .
Piston rod extension
in mm
G000
Trunnion mount
+90° vs. air ports
7000
Trunnion mount
+0° vs. air ports
H . . .
Piston rod extension in
mm with trunnion +90°
8 . . .
Piston rod extension in
mm with trunnion +0°
3 . . . Special rod end
Piston rod material male thread
C Chrome plated carbon steel
R Chrome plated stainless steel (17-4)
Piston rod material female thread
F Chrome plated carbon steel
G Chrome plated stainless steel (17-4)
Air reservoir
A Without piston rod
M C 0160
0000
Series
P1F Global ISO
1)
In standard temperature range -20°C to +80°C
2)
High and low temp option only with aluminium piston
3)
Only in combination with chrome or stainless steel plated piston rod material
4)
For air reservoir
P1F Cylinders in Stock, Cushions and Magnetic Piston Included
Stroke
(mm) 32 mm Bore 40 mm Bore 50 mm Bore 63 mm Bore 80 mm Bore
25 P1F-S032MC-0025-0000 P1F-S040MC-0025-0000 P1F-S050MC-0025-0000 P1F-S063MC-0025-0000 P1F-S080MC-0025-0000
40 P1F-S032MC-0040-0000 P1F-S040MC-0040-0000 P1F-S050MC-0040-0000 P1F-S063MC-0040-0000 P1F-S080MC-0040-0000
50 P1F-S032MC-0050-0000 P1F-S040MC-0050-0000 P1F-S050MC-0050-0000 P1F-S063MC-0050-0000 P1F-S080MC-0050-0000
80 P1F-S032MC-0080-0000 P1F-S040MC-0080-0000 P1F-S050MC-0080-0000 P1F-S063MC-0080-0000 P1F-S080MC-0080-0000
100 P1F-S032MC-0100-0000 P1F-S040MC-0100-0000 P1F-S050MC-0100-0000 P1F-S063MC-0100-0000 P1F-S080MC-0100-0000
125 P1F-S032MC-0125-0000 P1F-S040MC-0125-0000 P1F-S050MC-0125-0000 P1F-S063MC-0125-0000 P1F-S080MC-0125-0000
160 P1F-S032MC-0160-0000 P1F-S040MC-0160-0000 P1F-S050MC-0160-0000 P1F-S063MC-0160-0000 P1F-S080MC-0160-0000
200 P1F-S032MC-0200-0000 P1F-S040MC-0200-0000 P1F-S050MC-0200-0000 P1F-S063MC-0200-0000 P1F-S080MC-0200-0000
250 P1F-S032MC-0250-0000 P1F-S040MC-0250-0000 P1F-S050MC-0250-0000 P1F-S063MC-0250-0000 P1F-S080MC-0250-0000
320 P1F-S032MC-0320-0000 P1F-S040MC-0320-0000 P1F-S050MC-0320-0000 P1F-S063MC-0320-0000 P1F-S080MC-0320-0000
400 P1F-S032MC-0400-0000 P1F-S040MC-0400-0000 P1F-S050MC-0400-0000 P1F-S063MC-0400-0000 P1F-S080MC-0400-0000
(Revised 02-19-19)
