Chapter 4: Maintaining the PowerStation Performing Internal Maintenance
PA PowerStation User Guide 4-6
Removing the PowerStation from an Enclosure
To remove the PowerStation from it’s enclosure, follow the steps below.
1 Turn off the power to the unit.
2 Disconnect the following cables:
• Power Input cable
• Ground cable
• any communication cables
• any keyboard and mouse cables
3 Take off the clamps.
4 Place the PowerStation face down on a static dissipative mat, in a
location free from dirt and moisture and protected against static
discharge.
Opening the PowerStation
Once you have removed the PowerStation from it’s enclosure, you can
open it up. Follow the steps below.
1 Remove the CompactFlash card from it’s slot by pressing the eject
button on the side of the PowerStation, similiar to that shown below.
Figure 4-3: Eject Button
2 Press in the eject button to return it to it’s retracted position.
3 Remove the backshell screws on the PA PowerStation.
WARNING!
Explosion Hazard!
• Do not connect or disconnect cables unless the power has been
switched off, or the area is known to be safe.
CompactFlash
Card
CompactFlash
Eject Button
To Next Page
