The manufacturer will not be held respon-
sible for injuries resulting from use which
does not comply with the directions, or
from incorrect use.
General description
See the front fold-out page for
illustrations.
Delivery Contents
Unpack the equipment and check that it is
complete.
5 Container lid incl. motor housing
10 Metal container
11 Metal suction hose
12 Suction tube
13 Pleated lter
(already mounted)
14 Wire lter basket
(already
mounted)
- Instruction Manual
Dispose of the packaging material in a
proper manner.
Description of operation
The ash vacuum cleaner is tted with a
stable metal container with a cover. The
vacuum set comprises a exible metal suc-
tion hose and an aluminium suction hose.
A safety stop prevents the vacuum cleaner
from being operated without the lter or
lter basket.
A single-use thermal fuse permanently
disconnects the power circuit in event of
overheating or re inside the device.
The following describes the function of the
operating parts.
Overview
1 Power cord
2 Suction tube holder
3
Inspection window blockage
indicator
4a Carry handle
4b Retaining bracket for hose and
power cord
5 Container lid
6 On/off switch
7 Hose connection
8 Seal clips
9 Arched handle for metal con-
tainer
10 Metal container
11 Metal suction hose
12 Suction tube
13 Pleated lter
14 Wire lter basket
15a Safety stop pleated lter
15b Safety stop wire lter basket
16 Metal lugs for fastening the wire
lter basket
17 Air lter
18 Filter housing
19 Motor housing
