device.
- Do not place the batteries on radiators or expose them for a
45 ° could damage the device.
2. Initial mounting of the laser module:
Fig. 15.
(Figures 16-20)
3. Adjust the saw blade (4) to a max. cutting depth, move to
the 0° position and lock in place.
4. Dismantle the saw blade guard (2)
(not during initial assembly).
5. Release the two attachment bolts (28) and remove the table
insert.
AF8 supplied).
should be between 3 mm and max. 5 mm, (Figure 18).
9. Retighten the attachment bolts (29) and mount the table insert
(5).
10. Reattach the saw blade guard (2).
Mounting / dismounting
the Saw Blade Guard
(Figures 19)
-
de protection has already been carried out in
the previous assembly step.
1. Loosen the knurled nut and wing nut (31) of the saw blade
the riving knife (3).
2. Mount the bolt with the knurled nut and washer (31) so that
be able to move freely.
4. Dismantling is carried out in reverse order. Caution! Before
you start sawing, the saw blade guard (2) has to be lowered
onto the item being sawn.
Replacing the Table Insert
(Figures 16 and 20)
1. If it is worn or damaged, the table insert (5) has to be repla-
ced, as otherwise there is an increased risk of injury.
2. Remove the 2 countersunk screws (28).
reverse order.
Attaching/changing the Saw Blade
(Figure 21)
1. Caution! Remove the mains plug and wear protec-
tive gloves.
2. Dismantle the saw blade guard (2).
3. Remove the table insert (5) by releasing the two countersunk
screws (28).
4.
jaw spanner (k) (SW 22) to stop the motor spindle from turning.
5. Caution!
blade. Remove the loosened screw.
before attaching the new saw blade.
8. Insert and tighten the new saw blade in reverse order.
Caution! Note the direction of motion; the slope of
the cutting edge of the teeth must face the directi-
on of motion, i.e. forwards (see the arrow on the
saw blade guard.
9. Reattach and adjust the table insert (5) and the saw blade
guard (2).
10. Before you work with the saw again, a check must be
carried out to ensure that the protective devices are working
properly.
Connect the suction device
(Fig. 14)
1. Attach a suction hose to the suction adapter (18). If
necessary, secure the suction hose with a hose clamp to
prevent it from slipping off the suction adapter (18).
2. A household vacuum cleaner is not suitable as a suction de-
vice. Use a multi-purpose vacuum cleaner or a swarf extracti-
on machine.
Before putting into operation
base or similar item. For this, use the drill holes which are
located in the frame of the machine. For safe use on a work
bench, four mounted rubber feet are provided
• Before the machine is put into operation, all covers and safety
devices must be properly attached.
• In the case of wood which has already been worked with,
check for foreign bodies such as nails or screws etc.
• Before pressing the on/off switch, make sure that the saw bla-
de is correctly attached and that moving parts are free-running.
• Before connecting the machine, check that the data on the
type plate matches those of the mains system.
safety socket which is protected by a fuse of at least 16A.
• If possible, connect the device only to a socket with a residual
current circuit breaker (RCCB) with a tripping current of not
more than 30 mA.
