Performing Bevel Cuts
(Figure 36)
All bevel cuts are made using the parallel stop (6).
- Adjust the saw blade (4) to the desired angle.
- Adjust the parallel stop (6) according to the workpiece width
and height.
Performing Transverse Cuts
(Figures 29, 37)
groove (33) is to be used if the saw blade (4) also has to be
positioned at an oblique angle.
coming into contact with the saw blade guard.
- Use the stop rail (39).
- Switch on the saw.
of the saw blade in order to perform the cut.
the free workpiece which is cut off.
- Always push the transverse stop (40) so far forwards until the
workpiece is completely cut through.
- Switch the saw off again. Only remove sawing waste when
the saw blade has come to a standstill.
Cutting Chipboard
In order to prevent the cut edges chipping when the chipboard
is cut, the saw blade (4) should be adjusted so that it is not more
than 5 mm above the thickness of the workpiece.
Collection bag for wood residues
can be collected directly from the saw table to keep it clean and
free from obstructions. Under no circumstances may the wood
residues in the collection bag protrude beyond the collection bag
Transport
(Fig. 38/39)
1. -
nect it from the power supply.
2.
suction adapter (18).
3. Insert the saw blade with the help of the crank handle (12).
By turning the saw blade (4) anticlockwise, it moves
downwards.
4. At least two people should carry the power tool. Do not hold
the points as shown in (Fig. 38/39) to transport the
machine.
5. -
tions, e.g. when it is transported in motor vehicles.
6. Secure the power tool against tilting and sliding.
7. Never use the protective devices for handling or transport.
Cleaning and Servicing
Remove the mains plug before carrying out any adjust-
ments, maintenance or repair work.
You should have any repair and maintenance work that is
not described in these instructions carried out by our Ser-
vice Centre. Only use original parts.
Cleaning
The device must not be sprayed with water or
placed in water. Otherwise there is a risk of
electric shock.
of dust and dirt as possible. Wipe the device off with a clean
cloth or blow it out with compressed air at a low pressure.
• We recommend that you clean the device immediately after
every use.
• Clean the device regularly with a damp cloth and some soft
the plastic parts of the device. Make sure that no water can get
into the interior of the device.
• Oil the moving parts once a month in order to extend the tool
life. Do not oil the motor.
Storage
• Store the appliance in a dry place well out of reach of
children.
Waste disposal and environmental
protection
-
teries, accessories and packaging in an environmentally friendly
manner.
Electrical machines do not belong with domestic waste.
• Dispose of the batteries according to local standards. Hand
in the batteries at a used battery collection point where they
are recycled in an environmentally friendly manner. For more
information, please contact your local waste management
provider or our service centre.
• Defective units returned to us will be disposed of for free.
