Parrot Disco FPV User Manual

24
CIRCULAR LANDING
During circular landing, the Parrot Disco makes sure, by itself, that it
lands facing upwind so as to limit its landing speed.
1. Make sure you have an area of at least 80 meters in diameter to
land the Parrot Disco.
2. In the FreeFlight Pro application, press Circular landing .
> The Parrot Disco lands in a spiral.
80 m
50 m
10 m
Circular landing requires a lot of space.

Parrot Disco FPV Specifications

General

Product color	Black, White
Housing material	Carbon, Expanded polypropylene (EPP)
Maximum speed	22 m/s
Frequency band	2.4/5 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	1 rotors
Maximum weight capacity	- kg
Maximum operating distance	2000 m
Supported video modes	1080p
Maximum video resolution	1920 x 1080 pixels
Operating time	45 min
Battery capacity	2700 mAh
Cables included	USB
Moving control functions	-

Weight and Dimensions

Depth	580 mm
Width	1150 mm
Height	120 mm
Weight	750 g
