Parrot Disco FPV User Manual

30
SPARE PARTS
You can buy spare parts for the Parrot Disco from our online store :
www.parrot.com.
For more information on the assembly of spare parts, see the video
tutorials on our support page.
TECHNICAL SPECIFICATIONS
SENSORS
• Ultrasound
• Altimeter
• Hi-speed vertical camera
• Pitot Tube: speed sensor
INERTIAL NAVIGATION SYSTEM
• Three-axis gyroscope
• Three-axis accelerometer.
• Three-axis magnetometer
HARDWARE
• Dual core ARM 9 CPU
• Internal flash memory: 32GB
WI-FI AND TRANSMISSIONS
• Network access point
• AC Wi-Fi, 2 dual band antenna (2.4 and 5 GHz), multiple inputs
and outputs
• Up to 2km of range with the Parrot Skycontroller and the Parrot
Skycontroller 2.
REMOVABLE BATTERY
• 3 cell 2700mAh / 25A LipoBattery
• Battery life: 45 minutes
• Rated voltage: 11.1V
• 21.6A continuous discharge
• 3.5A max charge
• Operating range: -20°C-60°C

Parrot Disco FPV Specifications

General

Product color	Black, White
Housing material	Carbon, Expanded polypropylene (EPP)
Maximum speed	22 m/s
Frequency band	2.4/5 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	1 rotors
Maximum weight capacity	- kg
Maximum operating distance	2000 m
Supported video modes	1080p
Maximum video resolution	1920 x 1080 pixels
Operating time	45 min
Battery capacity	2700 mAh
Cables included	USB
Moving control functions	-

Weight and Dimensions

Depth	580 mm
Width	1150 mm
Height	120 mm
Weight	750 g
