Parrot Disco FPV User Manual

ENGLISH
31
DIMENSIONS
• Weight: 750 gr.
• Size: 1150 mm x 580 mm x 120 mm
• Wingspan: 1150 mm
GPS
• Integrated GPS
• GPS + GLONASS
PERFORMANCE
• Engine: 1280kv
• Servomotor: 5V
• Option of installing an SBUS, SUMD, CPPM radio receiver
VIDEO & PHOTOS
• Full HD 1080p Camera
• Video feed: 360p / 720p
FIRMWARE
• Linux & Open Source SDK for development
BATTERY CHARGER
• Input: 100-240V, 50h-60Hz, 1.2A
• Output: Max 12.6Vdc, 3.5A
• Maximum altitude: 2000m above sea level
• Operating range: 0°C-40°C
PARROT DISCO
• Operating range: 0°C-40°C
• Max current: 15A
• Rated voltage: 11.1V

Parrot Disco FPV Specifications

General

Product color	Black, White
Housing material	Carbon, Expanded polypropylene (EPP)
Maximum speed	22 m/s
Frequency band	2.4/5 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	1 rotors
Maximum weight capacity	- kg
Maximum operating distance	2000 m
Supported video modes	1080p
Maximum video resolution	1920 x 1080 pixels
Operating time	45 min
Battery capacity	2700 mAh
Cables included	USB
Moving control functions	-

Weight and Dimensions

Depth	580 mm
Width	1150 mm
Height	120 mm
Weight	750 g
