3. Throttle indicator
The throttle indicator is on the throttle grip. The fuel consumption curve on the throttle
indicator shows the relative amount of fuel consumed for each throttle position. Choose
the setting that offers the best performance and fuel economy for the desired operation.
1.Throttle indicator
4. Throttle friction adjuster
The throttle friction adjuster is on the tiller handle, which provides adjustable resistance to
movement of the throttle grip, and can be set according to operator preference.
To increase resistance, turn the adjuster
clockwise. To decrease resistance, turn the
adjuster counterclockwise. When constant
speed is desired, tighten the adjuster to
maintain the desired throttle setting.
WARNING:
Do not over-tighten the friction adjuster. If there is too much resistance, it could be difficult to
move throttle lever or grip, which could result in an accident.
26
1
