Parsun T40BM User Manual

3.7.1 Removing the propeller
1. Straighten the cotter pin and pull it out using a pair of pliers.
2. Remove the propeller nut, washer, and spacer (if equipped).
3. Remove the propeller and thrust washer.
1. Cotter pin
2. Propeller nut
3. Washer
4. Propeller
5. Thrust washer
3.7.2 Installing the propeller
CAUTION:
 Be sure to install the thrust washer before instating the propeller, otherwise the lower case and
propeller boss could be damaged.
 Be sure to use a new cotter pin and bend the ends over securely. Otherwise the propeller could
come off during operation and be lost.
1. Apply a marine grease or corrosion resistant grease to the propeller shaft.
2. Install the spacer (if equipped), thrust washer, and propeller on the propeller shaft.
42
2
3
1
4
5

Parsun T40BM Specifications

General

Brand	Parsun
Model	T40BM
Category	Outboard Motor
Language	English
