The procedure is as follows:
1. Remove the top cowling.
2. Remove the start-in-gear protection cable.
1. Start-in-gear protection cable
3. Remove the starter cover after removing the three bolts.
4. Prepare the engine for starting. For further information, see section 2.5.
5. Insert the knotted end of the emergency starter rope into the notch in the flywheel rotor and wind the
rope several turns around the flywheel clockwise.
54
