750w² Monitor Instruction Manual
4 Monitor Configuration
This section explains the
options available under the
Monitor Configuration menu
(Figure 10 and 11).
Press the OK key to select
4.1 Bleeper
The Bleeper can be switched off if required (Figure 12).
Press OK to enter Bleeper setup.
4.2 Backlight
The backlight can be set to:
“Always Off”
“Always On”
“On After Keypress” (Figure 13).
4.3 Backlight Brightness
The Backlight Brightness option determines the
intensity of the display backlight (when enabled).
The current brightness value will be displayed on the
screen (Figure 14).
4.4 Contrast
The Contrast Option determines the effective intensity
of the displayed.
The current contrast value will be displayed on the
screen (Figure 15).
4.5 Auto Shutdown
The monitor will switch off the monitor 60 seconds
after the last key press.
This can be inhibited by selecting ‘Off’ (Figure 16)
Page 10 of 20 228538IM Issue 09 Issue Date 20/01/2020
Figure 13
Figure 15
Figure 14
Figure12
Figure 11
Figure 10
Figure 16
