750w² Monitor Instruction Manual
3.2.2 User Value Entry (Figure 8)
When a numerical value is to be set, the current
value will be displayed with a flashing cursor. The
range of adjustment of the value is predefined and
therefore only values within this range can be
entered.
To adjust a value, the keys are used to select a
digit and the keys are used to increase/decrease the digit.
When the new value has been set pressing the OK key will store it and exit from
the value adjustment display.
To exit without saving changes press the MENU key.
3.2.3 User Text Entry (Figure 9)
Using this method of data entry, the user is able to
enter or edit text and is used for user defined
measurement title and units.
The text string is displayed with a flashing cursor
indicating the selected character.
The keys are used to select a character, and the keys to change the
selected character.
When all changes are complete press the OK key to store the text.
To exit without saving changes press the MENU key.
228538IM Issue 09 Date 20/01/2020 Page 9 of 20
