MIC 1400 Manual Edition 1
4
Figures & Tables
Figure 1-1 Controller Display Illustration 6
Figure 2-1 Panel Cut-Out Dimensions 7
Figure 2-2 Main Dimensions 8
Figure 2-3 Panel Mounting the controller 8
Figure 2-4 Noise Suppression 11
Figure 2-5 Noise Suppression 12
Figure 2-6 Wiring Label 13
Figure 2-7 AC Power 14
Figure 2-8 Thermocouple Input 14
Figure 2-9 RTD Input 14
Figure 2-10 Volt, mV mADC Input 15
Figure 2-11 Remote Digital Connections 15
Figure 2-12 Relay Output 1 16
Figure 2-13 SSR Driver Output 1 16
Figure 2-14 mADC Output 1 16
Figure 2-15 Relay Output 2 17
Figure 2-16 SSR Driver Output 2 17
Figure 2-17 mADC Output 2 17
Figure 2-18 Relay Output 3 18
Figure 2-19 SSR Driver Output 3 18
Figure 2-20 mADC Output 3 18
Figure 4-1 Proportional Bandwidth Effect on Output 37
Table 3-1 Enable Mode Configuration Procedures 24
Table 3-2 Program Mode Configuration Procedures 25
Table 3-3 Tune Mode Configuration Procedures 27
Appendices cont.
C - Hardware Definition Code 56
D - Input Range Codes 58
E - Specifications 60
F - Model Number Hardware Matrix 66
G - Software Reference Sheet 67
