Partlow MIC 1400 - Figure 2-2 Main Dimensions

MIC 1400 Manual Edition 1
8
FIGURE 2-2
Main Dimensions
FIGURE 2-3
Panel Mounting the Controller
Mounting Clamp
Controller Housing
Tongues on mounting clamp engage in
ratchet slots on controller housing
96 mm
(3.78 in.)
96 mm
(3.78 in)
100 mm (3.94 in.)
Side View
10 mm (0.39 in.)
