MIC 1400 Manual
Edition 158
Appendix D
Input Range Codes
The input ranges available (selectable via the front panel) are:
For Thermocouple Inputs
INPUT DISPLAYED INPUT DISPLAYED
TYPE RANGE CODE TYPE RANGE CODE
R 0 - 1650°C 1127 K 0 - 760°C 1719
R 32 - 3002°F 1128 K 32 - 1400°F 1720
S 0 - 1649°C 1227 K 0 - 1373°C 1723
S 32 - 3000°F 1228 K 32 - 2503°F 1724
J 0.0 - 205.4°C 1415 L 0.0 - 205.7°C 1815
J 32.0 - 401.7°F 1416 L 32.0 - 402.3°F 1816
J 0 - 450°C 1417 L 0 - 450°C 1817
J 32 - 842°F 1418 L 32 - 842°F 1818
J 0 - 761°C 1419 L 0 - 762°C 1819
J 32 - 1402°F 1420 L 32 - 1404°F 1820
T -200 - 262°C 1525 B 212 - 3315°F 1934
T -328 - 504°F 1526 B 100 - 1824°C 1938
T 0.0 - 260.6°C 1541
T 32.0 - 501.1°F 1542
For RTD Inputs
Note: Input conditioning jumper JU1 needs to be changed, see Appendix B.
0 - 600°C 2221 0.0 - 100.9°C 2295
32 - 1112°F 2222 32.0 - 213.6°F 2296
32 - 572°F 2229 -200 - 206°C 2297
-101.0 - 100.0°C 2230 -328 - 403°F 2298
-149.8 - 212.0°F 2231 -101.0 - 300.5°C 7201
0 - 300°C 2251 -149.8 - 572.9°F 7202
INPUT DISPLAYED INPUT DISPLAYED
RANGE CODE RANGE CODE
