MIC 1400 Manual
Edition 152
FIGURE B-3 CPU PWA
LJ3
LJ1, LJ2, LJ3
Jumper Position
RTD, DC (mV)
T/C
DC (mA)
DC (V)
Input Type
LJ2
LJ1
IC6
None (parked)
LJ3
LJ2
LJ1
