MIC 1400 ManualEdition 1 59
For DC Inputs
Note: Input conditioning jumper JU1 needs to be changed, see Appendix B.
Also, the Hardware Definition Code for the input type must also be changed,
see Appendix C.
0 - 20mA 3413 0 - 5V 4445
4-20mA 3414 1 - 5V 4434
0 - 50mV 4443 0 - 10V 4446
10 - 50mV 4499 2 - 10V 4450
INPUT DISPLAYED INPUT DISPLAYED
RANGE CODE RANGE CODE
