3
Contents
Page
1.0 Safety Precautions 4-5
2.0 Product Description 5
3.0 Technical Specications 6
4.0 Installation 6
4.1 Location 6
4.2 Input and Grounding Connection 6
5.0 Description of Controls 7
and Torch Connections
6.0 Operation 8-10
6.1 Use of Controls 8
6.2 Language of Operation 8
6.3 Process Selection 8
6.4 MIG Welding Preparing the Machine 9-10
7.0 Setting the Machine for Welding 10-19
7.1 MIG Torch Selection 10
7.2 MIG SYN - Synergic MIG Welding 10-11
7.3 MIG MAN - Manual MIG Welding 11
7.4 Remote Control MIG Torch 11
7.5 MIG Welding Procedure 12
7.6 MMA Welding 12
7.7 TIG Welding 12
7.7.1 TIG Torch Selection 12
7.7.2 TIG Torch Installation 13
7.7.3 TIG Welding Setup 13-15
7.7.4 TIG Welding Guide 15
7.7.5 DC TIG Welding (No Pulse) 15-16
7.7.6 AC TIG Welding (No Pulse) 16-17
7.7.7 TIG Welding (With Pulse) 17-18
7.8 Saving to Memory 18
7.9 Process Switch 18-19
8.0 Fault Finding 19-22
8.1 MIG Welding Problems 19-20
8.2 MMA Welding Problems 21
8.3 TIG Welding Problems 22
9.0 Control Torch Schematic 23
10.0 Accessories 24
10.1 Feed Rolls 24
10.2 Torch Spares 24
10.3 Gas Equipment 24
11.0 EC Declaration of Conformity 25-26
11.1 RoHS Compliance Declaration 25
11.2 WEEE Statement 26
11.3 Statement of Warranty 26
