Resetting the SmartNode device when it is initially powered off 57
SmartNode 4131 User Manual F • Reset Button Functions
4. The Power LED will begin a blink pattern (see table 10). Release the Reset button.
5. Pressing and releasing the Reset button will cycle through the blink patterns.
6. 10 seconds after the last Reset button press, an action will be performed based on the selected pattern.
Table 10. Using the Reset button to switch to a backup image or erase flash memory
LED Blink Pattern Action
1-blink, pause Boot normally
2-blinks, pause Switch to backup image, then boot (boot normally if the device only has a
single image).
3-blinks, pause Erase entire contents of flash memory (no exceptions), then boot.
Note Erasing flash memory also deletes previously pur-
chased and loaded software license keys.
