About this guide
This guide describes the SmartNode 4131 hardware, installation and basic configuration. For detailed software
configuration information refer to the
Trinity Software Configuration Guide and the available Knowledgebase.
Audience
This guide is intended for the following users:
• Operators
• Installers
• Maintenance technicians
Structure
This guide contains the following chapters and appendices:
• Chapter 1, starting on page 14, provides information about gateway features and capabilities
• Chapter 2, starting on page 19, contains an overview describing gateway operation and applications
• Chapter 3, starting on page 23, provides quick start hardware installation procedures
• Chapter 4, starting on page 28, provides quick-start procedures for configuring the SmartNode gateway
• Chapter 5, starting on page 34, contains information on contacting Patton technical support for assistance
• Appendix A, starting on page 37, contains compliance and regulatory information for the gateway
• Appendix B, starting on page 40, contains specifications for the gateway
• Appendix C, starting on page 45, provides cable recommendations
• Appendix D, starting on page 49, describes the gateway’s ports and pin-outs
• Appendix E, starting on page 52, lists the factory configuration settings for SmartNode 4131
• Appendix F, starting on page 54, describes the Reset button functions
• Appendix G, starting on page 58, provides license information that describes acceptable usage of the soft-
ware provided with the SmartNode 4131
For best results, read the contents of this guide before you install the gateway.
