Paul CLIMOS F 200 Basic - 11 Error Handling; Error Fan

Error handling
57
11 Error handling
11.1 Error fan
Measure
230 V power supply
O.K.?
Yes
No
Yes
Replacement
of the fans
Replacement
fan slave
Hall signal
defective
Measure
1,7-12 V signal
O.K.?
Yes
No
Replacement of
the master
(assume settings)
O.K.
Check
fuse of fan at
master controller
(5 A M)
No
Replace
the fuse
restart
Error fan
Hall 1 Hall 2
Disconnect the
power supply.
Fan wheel
damaged?
No
Restart the device
wait 20 s.
Yes
WARNING!
Do not touch the board
for under 230 V power
supply live components!
