Page 73
The following table lists the registers of the output area (written by the master and acquired by the
instrument), common to all PROFIBUS, PROFINET, ETHERCAT, ETHERNET / IP Fieldbuses.
The registers are 16 bit in size. The registers written by the master in the output area, are read by the
instrument at a fixed frequency of 150 Hz. (80 Hz in case of PROFIBUS)
The size of the output area configured in the master fieldbus must match the size configured in the
instrument.
OUTPUT DATA AREA
Byte
Register
address
OUTPUT AREA REGISTER Note
1-2 0 Command Register See relevant table.
3-4 1 Data Register (MSB) INT. value - Most significant word (See Table)
5-6 2 Data Register (LSB) INT. value - Least significant word (See Table)
7-8 3 Monitor register This value corresponds to the same register in the input area.
9-10 4 Set-Point 1 (MSB) INT. value - Most significant word
11-12 5 Set-Point 1 (LSB) INT. value - Less significant word
13-14 6 Set-Point 2 (MSB) INT. value - Most significant word
15-16 7 Set-Point 2 (LSB) INT. value - Less significant word
17-18 8 Capacity of load cells (MSB) INT. value - Most significant word
19-20 9 Capacity of load cells (LSB) INT. value - Less significant word
21-22 10 Sensitivity of load cells INT. value
23-24 11 Weight division value See relevant table.
25-26 12 Decimals See relevant table.
27-28 13 Fixed Tare (MSB) INT. value - Most significant word
29-30 14 Fixed Tare (LSB) INT. value - Less significant word
31-32 15 Stand-by function INT. value
33-34 16 Keypad Lock function See relevant table.
35-36 17 Password function INT. value
37-38 18 Peak function See correspondence on page 50
39-40 19 Data-Logger function See correspondence on page 51
41-42 20 Data-Logger Trigger See correspondence on page 51
43-44 21 Data-Logger function See correspondence on page 51
45-46 22 Filter factor See correspondence on page 48
47-48 23 Output rate ADC See correspondence on page 48
49-50 24 Number of readings on average INT. value
51-52 25 Monotony Time INT. value
53-54 26 Oscillations Time INT. value
55-56 27 Oscillations Range INT. value
57-58 28 Full Scale (MSB) INT. value - Most significant word
59-60 29 Full Scale (LSB) INT. value - Less significant word
61-62 30 Weight stability See correspondence on page 46
63-64 31
Auto zero when switching on (MSB)
INT. value - Most significant word
65-66 32
Auto zero when switching on
(LSB) INT. value - Less significant word
67-68 33 Zero tracking See correspondence on page 47
69-70 34 Resettable Divisions (key >0<) INT. value
71-72 35 Input 1 function See correspondence on page 43
73-74 36 Input 2 function See correspondence on page 43
75-76 37 Input 1 mode —Function See correspondence on page 43
