PAX D210E User Manual

• Power On - Press and hold power button for 3 seconds
until LCD screen backlight comes on. If terminal is turned
on successfully, the NewBook Payments logo will appear
on screen and you will hear a beep.
• Allow the terminal to automatically run through its
initialisation cycle before the EFTPOS “ready” screen
appears. At this point the terminal is ready for use.
CONNECTING USING 3G (SIM CARD)
INTERNET CONNECTION
• In order to process payments, your D210e EFTPOS terminal has to be connected to
the internet. The D210e will be setup to use either cellular, Wi-Fi, or the separate
B210 base.
• If the D210e is setup for cellular then the will display the current signal
• strength.
• If the D210e is setup to use the intelligent base then the will light up.
• If the D210e is setup to use Wi-Fi then it will need to be setup to use your wireless
modem/router, mobile phone (Wi-Fi personal hotspot) or a mobile Wi-Fi hotspot device.
Wi-Fi signal strength is shown by the
• To set up Wi-Fi on your terminal, you will need to ensure that you have access to an
active internet connection. If using a modem/router, ensure that it does not have any
special conguration settings, network trafc restrictions or lters.
• Please be aware that if your network signal is not strong enough you may experience
issues using the D210e. NewBook does not recommend using public or unsecured
Wi-Fi networks to process payments.

PAX D210E Specifications

General

Brand	PAX
Model	D210E
Category	Payment Terminal
Language	English
