Smartpay two-piece countertop EFTPOS is a Pax S300 customer facing touchscreen PINpad plugged into a
merchant facing Pax S80c or Pax S800 base unit.
For EFTPOS terminal enquiries, issues or support contact Smartpay Technical Helpdesk on
0800 476 278 or email customer.service@smartpay.co.nz
Which Plugs Go Where?
On the back of your S80 and S800 EFTPOS terminals there are ports available for plugging in the required cables.
These ports are labelled but can be dicult to read. For ease of use we have included diagrams and descriptions.
LAN/RS232B
An Ethernet cable should be plugged in here to connect the terminal to a Broadband/Fibre
Internet connection.
LINE
If you use a dial-up connection, the phone cable should be plugged in here.
POWER
The power cable supplied with your terminal plugs in here. Plug the other end into your wall
socket or a power strip.
RS232A
If you are using a Keylink interface to your ECR/POS system connect the Keylink cable or
accessory supplied here.
PINPAD
Plug the S300 PINpad in here for two-piece EFTPOS setup.
NOTE: When the S300 is plugged into an S800 you will need to pull the power cable or turn
S800 o at the wall to manually power o the S300.
