NMS044 Reference Manual Physical Characteristics B-1
Appendix B Technical Specifications
B.1 Physical Characteristics
DEPLOYMENT SPACE REQUIREMENTS
The NMS044 system, when deployed, requires a 3 m (10-foot) diameter on the
ground, with a 2 m (6.5-foot) overhead clearance minimum. Since sound
reflections are possible when other large objects are nearby, we recommend
additional clearance.
RECOMMENDED SOLAR PANELS
If you use solar panels other than those provided from Larson Davis, the NMS
system can support solar panels providing up to 140 Watts.
Table B.1 Weight by Package and by Component
Full Package
NMS044 with 60W solar panel (SLP001), Li
Battery, and cases
23 kg (50 lbs)
Components
NMS044 only 8.18 kg (18 lbs)
60 Watt solar panel only (SLP001) 9 kg (19.85 lbs)
100 Watt solar panel only (SLP002 ) 12.27 kg (27.05 lbs)
Telescoping pole, mic shroud, and
mic/preamp combo in bag
1.92 kg (4.2 lbs)
LiFePo Battery (BAT019) 5.8 kg (12.8 lbs)
SLA Battery (BAT021) 11.2 kg (24.7 lbs)
Table B.2 Dimensions by Component
NMS044 Case 61 cm x 35.5 cm x 18 cm
(24” x 14” x 7”)
60 W Solar Panel (SLP001) 66 cm x 35.5 cm x 8 cm
(26” x 14” x 3”)
100 W Solar Panel (SLP002) 50 cm x 68.5 cm x 8 cm
(20” x 27” x3”)
Canvas Bag 48 cm x 23 cm x 15 cm
(19” x 9” x 6”)
B
