4LHD/4LHDX Application Manual
Powertrain Control Solutions
REV 1.1
PCS C6 Extension Housing
This replacement package holds all the same specications as the old Ford C6 w/ drum parking brake option. Shown in
Figures 2.2.3-9 to 2.2.3-10. This utilizes the original brake housing, drum, driveshaft yoke, and other hardware to correctly
seal and operate. Same as the original, our output shaft is an SAE10B spline. Reference SAE Standard J499 for full
spline detail.
Figure 2.2.3-9: PCS 4LHD/4LHDX with C6 Bellhousing and C6 Output
