Page 50
Ph: 804.227.3023
10511 Old Ridge Rd. Ashland, VA 23005
4LHD/4LHDX Application Manual
Powertrain Control Solutions
REV 1.1
9. Grasp lter rmly while pulling down with a twisting
motion in order to remove the lter.
Reference Figure 2.3.8-4.
10. If the lter is going to be replaced, remove the lter seal. The
lter seal may be stuck in the pump; if necessary, carefully
use pliers or another suitable tool to remove the seal.
Reference Figure 2.3.8-5.
11. Discard the seal.
Figure 2.3.8-4
Figure 2.3.8-5
